1U WIO A+ Server AS -1114S-WN10RT (AS -1114S-WN10RT-EU)

Er is geen beschrijving voor dit product.

Loading price... (€0.00)

Loading price...

Beschikbaarheid opvragen

Minimaal 1 jaar Carry-in-garantie voor servers

Wij assembleren en testen uw bestelling zorgvuldig

Laagste prijsgarantie

Supermicro Product ID: AS-1114S-WN10RT-EU

Hulp Nodig? Contacteer onze experts

Beschikbaar van maandag tot vrijdag, 09:00 - 17:30 uur

+31 (0) 85 301 85 85

Begin Chat

Now online: 9.00 am - 17.30 pm

Loading: Specificaties...

Specificaties

Key Features
Virtualization
Cloud Computing
All Flash Storage

1. Single AMD EPYC™ 7003/7002 Series Processor
(The latest AMD EPYC™ 7003 Series Processor with AMD 3D V-Cache™ Technology requires BIOS version 2.3 or newer)

2. 16 DIMMs; up to 4TB 3DS ECC
DDR4-3200MHz RDIMM/LRDIMM

3. 2 PCI-E 4.0 x16 (FHHL) slots,
1 PCI-E 4.0 x16 (LP) slot

4. Integrated IPMI 2.0 + KVM with
dedicated LAN
• Software Out of Band License key
(SFT-OOB-LIC) included for
OOB BIOS management

5. 10 Hot-swap U.2 NVMe4/NVMe3/SATA3
fully hybrid drive support

6. 2x 10GBase-T LAN ports via
Broadcom BCM57416 Controller

7. 1 VGA,
7 USB 3.0 (4 rear, 2 front, 1 Type A)

8. 2 SuperDOM (Disk on Module) ports

9. 750W Redundant Power Supplies
Platinum Level High-efficiency
(Full redundancy based on
configuration and application load)


Product SKUs

AS -1114S-WN10RT	Standard version with PWS-706P-1R (Platinum Level)
AS -1114S-WN10RT-EU	European version with PWS-861A-1R (Titanium Level)


Motherboard

Super H12SSW-NTR


Processor/Cache

CPU	Single AMD EPYC™ 7003/7002 Series Processor (The latest AMD EPYC™ 7003 Series Processor with AMD 3D V-Cache™ Technology requires BIOS version 2.3 or newer) Socket SP3 Support CPU TDP up to 280W
Cores	Up to 64 Cores


System Memory

Memory Capacity	16 DIMM slots Up to 4TB 3DS ECC DDR4-3200MHz RDIMM/LRDIMM
Memory Type	DDR4 3200 MHz Registered ECC, 288-pin gold-plated DIMMs


On-Board Devices

Chipset	System on Chip
SATA	SATA3 (6Gbps)
Network Controllers	Dual 10GBase-T LAN with via Broadcom BCM57416
IPMI	Support for Intelligent Platform Management Interface v.2.0 IPMI 2.0 with virtual media over LAN and KVM-over-LAN support
Video	ASPEED AST2500 BMC


Input / Output

SATA	2 SATA3 (6 Gbps) ports
LAN	2 RJ45 10GBase-T ports 1 RJ45 Dedicated IPMI LAN port
USB	7 USB 3.0 ports (4 rear, 2 front, 1 Type A)
Video	1 VGA port
DOM	2 SuperDOM (Disk on Module) ports


System BIOS

BIOS Type	AMI 256Mb SPI Flash ROM


Management

Software	Super Doctor 5 Watch Dog SUM IPMI 2.0, KVM with dedicated LAN
Power Configurations	ACPI / APM Power Management


PC Health Monitoring

CPU	Monitors for CPU Cores, Chipset Voltages, Memory. 4+1 Phase-switching voltage regulator
FAN	Fans with tachometer monitoring Status monitor for speed control Pulse Width Modulated (PWM) fan connectors
Temperature	Monitoring for CPU and chassis environment Thermal Control for fan connectors
