IdeaHub Board S2 (86 inch)
Vraag gratis offerte aan voor prijsinformatie. Binnen 1 werkdag ontvangt u een prijsopgave van een expert.
Huawei Product ID: 55150652
Hulp Nodig? Contacteer onze experts
Beschikbaar van maandag tot vrijdag, 09:00 - 17:30 uur
| Product Name | HUAWEI IdeaHub S2 |
| Product model | 86": IHS2-86SA |
| Product dimensions(H x W x D) | 86": 1212.0 mm x 1953.0 mm x 91.8 mm |
| Net weight | 86": 62.0 kg |
| Gross weight (including the package) | 86": 73.5 kg |
| * | The dimensions and weight may vary with configuration, manufacturing process, and measurement method. The product height includes the camera (57 mm). |
| Device | 1 |
| Stylus pens | 2 |
| Cable | Power cable x 1 |
| Wall-mounted bracket | Optional (65", 75", and 86") |
| Rolling stand | Optional (65", 75", and 86") |
| IdeaShare Key | Optional (Type-A/Type-C port) |
| OPS | Optional |
| Resolution | 4K (3840 x 2160 pixels) |
| Backlight type | D-LED |
| Screen Lamination | Zero-gap bonding |
| Latency | 16 ms |
| Touch sensing distance | ≤ 1.5 mm |
| Intelligent writing recognition | Supports recognition of Chinese, English, French, Japanese, Spanish, Russian, Portuguese, Italian and 11 types of graphics |
| Resolution | 4K |
| Camera sharpness | 1800 lines |
| Lens cap for privacy protection | √ |
| Horizontal FoV | 80° |
| TV distortion | ＜2% |
| Speaker frequency domain | 100 Hz to 20 kHz |
| Number of speaker units | 4 |
| Speaker total power | 40 W |
| Sound pickup angle | 180° |
| Sound pickup distance | 12 m |
| Microphone frequency domain | 80 Hz to 20 kHz |
| Optimized sound pickup | Sound location, echo cancellation, and automatic gain control |
| Native meeting apps | Huawei Cloud Meeting and WeLink |
| Dual streams (audio/video + data sharing) | 1080p30fps+1080p30fps/4K8fps |
| BYOM | √ |
| Auto-Framing | √ |
| Intelligent tracking | √ |
| Acoustic baffle | √ |
| DNN-based dereverberation | √ |
| CPU | 8-core |
| RAM | 8 GB |
| Flash | 64 GB |
| OS | HarmonyOS, Windows (OPS required) |
| Security | Embedded encryption chip that supports H.235, STARTTLS, TLS, SRTP encryption, Chinese cryptographic algorithms, secure boot, and TEE |
| Language | Simplified Chinese, English, French, Japanese, Arabic, Spanish, Russian, German, Portuguese, and Italian |
| Wi-Fi module | Wi-Fi 6 |
| Wi-Fi frequency | 2.4 GHz + 5 GHz |
| NFC | √ |
| Video input | HDMI cable x 1 |
| Video output | HDMI cable x 1 |
| Audio input | ·3.5 mm (line-in) x 1 ·HD-AI x 1 |
| Audio output | 3.5 mm (line-out) x 1 |
| Other ports | ·USB Type-A 3.0 x 3 ·USB Type-C x 1 ·RJ45 (10/100/1000 Mbit/s LAN) x 1 |
HUAWEI IdeaHub S2
Built on the next-gen hardware platform architecture, HUAWEI IdeaHub S2 is equipped with Bring Your Own Meeting (BYOM), HD immersive meeting quality, Wi-Fi 6 for direct projection, and ultra-low writing latency, easily adapting to mainstream cloud meeting apps. It is a perfect solution for boundless collaboration and communication to fit in any room, such as regular meeting rooms, executive offices, and open office areas.
BYOM
Bring Your Own Meeting (BYOM) with seamless transfer from personal devices to HUAWEI IdeaHub S2.
Wi-Fi 6 for Direct Projection
One-step projection using Wi-Fi Direct without the need for devices to share the same local area network (LAN).
Collaboration Unbounded
Multi-Window and App Multiplier deliver an enriched office ecosystem.
Professional-Level 4K Video Camera
2 μm² ultra-large photosite size doubles the signal-to-noise ratio (SNR). Huawei-developed AI algorithm ensures true-to-life, natural clarity.
AI-powered Audio and Video
Voice tracking, Auto-Framing, and acoustic baffle deliver immersive experience. 12-meter sound pickup, DNN-based de-reverberation, and AEC algorithm ensure clear voice from far away.
Intelligent Whiteboard
Annotate on full screen in full color with an all-new toolbar. Writing is effortlessly smooth with intelligent recognition and ultra-low latency.
Enterprise-Level Information Security for E2E Reliability
Cloud-pipe-device-chip full-link protection, protecting enterprise information assets.
CC EAL5+ high-level security certification for global commercial systems.
