1U SuperServer 1028UX-LL1-B8 (Complete System Only) (SYS-1028UX-LL1-B8)

1028UX-LL1-B8 | 1U | SuperServers | Products | Super Micro Computer - Inc. - SYS-1028UX-LL1-B8 - SS1028UX-LL1-B8 - 1028UX-LL1-B8 - Hyper-Speed -

Loading price... (€8748.55)

Loading price...

Verzending binnen 10-15 werkdagen

Try before you buy

Beschikbaarheid opvragen

Minimaal 1 jaar Carry-in-garantie voor servers

Wij assembleren en testen uw bestelling zorgvuldig

Laagste prijsgarantie

Supermicro Product ID: SYS-1028UX-LL1-B8

Hulp Nodig? Contacteer onze experts

Beschikbaar van maandag tot vrijdag, 09:00 - 17:30 uur

+31 (0) 85 019 62 42

Begin Chat

currently offline

Loading: Specificaties...

Specificaties

 Qualified low latency NICs here

Key Features
 Support Hyper-Speed

1. Dual Intel® Xeon® processor
E5-2643 v4

2. 8x 8GB DDR4-2400MHz (Default), up to
DDR4- 2400^†MHz ; 16 DIMM slots

3. Expansion slots via riser card:
    2 PCI-E 3.0 x16, Full-height, 10.5" Length
    1 PCI-E 3.0 x8, Low-profile
    1 PCI-E 3.0 x8 SAS3 integrated

4. 4 Gigabit Ethernet LAN ports

5. Integrated IPMI 2.0 with KVM and
Dedicated LAN

6. 10 Hot-swap 2.5" Drive Bays:
    8 SAS3 (Broadcom 3108), 2 SATA3,
    2 NVMe ports support via
    optional AOC-URN2-I2XT
    (with 2x 10GBase-T ports)

7. 8 heavy duty fans w/ optimal
fan speed control

8. 750W Redundant Power Supplies
Platinum Level (94%+)


Product SKUs

SYS-1028UX-LL1-B8	SuperServer 1028UX-LL1-B8 (Black)


Motherboard

Super X10DRU-XLL


Processor/Cache

CPU	Intel® Xeon® processor E5-2643 v4 (Included) * Dual Socket R3 (LGA 2011)
Cores / Cache	Up to 6 Cores / Up to 20MB Cache
System Bus	QPI up to 9.6 GT/s
Note	^† BIOS version 2.0 or above is required
Note	* Please contact Supermicro Technical Support for additional information about frequency optimized CPUs and specialized system optimization.


System Memory

Memory Capacity	8x 8GB DDR4-2400MHz (Default) 16x 288-pin DDR4 DIMM slots Up to 2TB^† ECC 3DS LRDIMM, 768GB ECC RDIMM
Memory Type	2400^†/2133/1866/1600MHz ECC DDR4 SDRAM 72-bit
DIMM Sizes	RDIMM: 64GB, 32GB, 16GB, 8GB, 4GB LRDIMM: 64GB, 32GB 3DS LRDIMM: 128GB
Memory Voltage	1.2 V
Error Detection	Corrects single-bit errors


On-Board Devices

Chipset	Intel® C612 chipset
SAS	Broadcom 3108 SAS3 (12Gbps) controllers; RAID 0, 1, 5, 6, 10, 50 support
SATA	SATA3 (6Gbps) with RAID 0, 1, 5, 10
IPMI	Support for Intelligent Platform Management Interface v.2.0 IPMI 2.0 with virtual media over LAN and KVM-over-LAN support ASPEED AST2400 BMC
Graphics	ASPEED AST2400 BMC


Input / Output

SAS	8 SAS3 (12Gbps) ports
SATA	2 SATA3 (6Gbps) ports
NVMe	2 NVMe ports support via optional Ultra Riser card (AOC-URN2-i2XT)
LAN	4 RJ45 Gigabit Ethernet ports 1 RJ45 Dedicated IPMI LAN port
USB	5 USB 3.0 ports (2 rear, 2 via header, 1 Type A)
Video	1 VGA Connector
Serial Port / Header	1 Fast UART 16550 serial 1 COM port (rear)


System BIOS

BIOS Type	128Mb SPI Flash EEPROM with AMI BIOS
BIOS Features	Plug and Play (PnP) APM 1.2 PCI 2.3 ACPI 1.0 / 2.0 / 3.0 / 4.0 USB Keyboard support SMBIOS 2.7.1 UEFI 2.3.1
